Thermal Viewer IBEX335-LRF THERMTEC

1.690,00

The ThermTec Ibex 335 LRF is a new high precision thermal viewfinder designed to provide a sharp, stable and detailed image even in the most demanding conditions. Thanks to its thermal sensor of 384 × 288 pixels sensitively <18 mK and a lens of 35 mm, The new, high resolution, high resolution, long range target detection provides clear target detection over long distances and excellent performance in low visibility environments.

Your screen AMOLED 0.5 inch with resolution 1600 × 1200 px offers a clear and comfortable viewing experience, allowing switching between viewing modes according to the user's preference. The optical magnification of 3,7×, The new digital zoom, combined with continuous digital zoom and super-resolution technology, allows the image to be enlarged without sacrificing detail.

It incorporates a laser range finder (LRF) with a range of up to 1,000 metres, This is an indispensable tool to know the real distance to the target and improve shooting accuracy. It also includes advanced functions such as ballistic calculation, AI-assisted automatic calibration and the technology RAV, The camera's internal memory, which activates video recording automatically when the weapon recoils, is also available. Its internal memory of 64 GB allows you to store videos and photos without the need for additional accessories.



Features IBEX 335L
Type Uncooled (Uncooled)
Detector resolution 384×288
Pixel size 12 μm
NETD <18 mK
Spectral range 8-14 μm
Frame frequency 50 Hz
Detection range 1800 m
Objective lens 35 mm
Field of vision 7.5° x 5.7°
Field 100 m 13.2 x 9.9
Optical magnification 3.7x
Digital zoom 1.0-4.0x
Eye relief 50 mm
Exit pupil diameter 6 mm
Diopter ±5D
Reticle / Colour 7 / 6
Screen AMOLED, 0.5 inch, 1600×1200
Colour palette 6
Maximum recoil in rifled weapon 6000 J
Weapon mount 30 mm standard rings
RAV / TASS backtracking recording Yes / Yes
Audio recording Yes
Manual zero / Profiles / Freeze zero Yes / 6 / Yes
Image within an image Yes
LRF 1000 m
Ballistic calculator Yes
Image calibration Manual / Automatic
Photo/video playback Yes
Built-in memory 64 GB
Port Type C Data transfer and battery charging
Hotspot Yes
Battery Replaceable, 1 x 18650
Battery life 6 h
Operating temperature -20 ~ +50 °C
IP rating IP67
Weight 770 ± 5 g (without battery)
Dimensions 344 × 86 × 70 mm
External cable USB for data
Other accessories Eye sunshades and others

ThermTec Ibex-L-Serie L_Image Viewer_User Manual
