| Brand |
ThermTec |
| Sensor type |
VOx microbolometer uncooled |
| Resolution |
640×512 pixels |
| Pixel size |
12µm |
| NETD |
≤20mK@300K |
| Spectral range |
8～14μm |
| Lens |
20/60mm (F#1.0, manual focus) |
| Distance meter |
LRF, laser, up to 1,000 metres |
| Shutter technology |
Shutterless (Shutterless military technology) |
| Increases |
1,1X / 3,2X |
| Viewing angle |
21.7° x 17.4° / 7.3° x 5.9° / 21.7° x 17.4° / 7.3° x 5.9° |
| Digital zoom |
1x～5x continuous |
| Colour palettes |
6 |
| Display type |
AMOLED 0.39″, resolution 1024×768 pixels, 3 picture modes |
| Dioptric adjustment |
-5～+5 |
| Eye distance |
50mm |
| Maximum recoil force |
6000J |
| Assembly |
2x 30mm Weaver rings |
| Zeroing |
Automatic / Manual |
| Video and image playback |
YES |
| Audio recording on the shot |
YES |
| Reticle |
7 (central point black, white, red and blue) |
| Internal memory |
16 GB |
| Heat Seeker |
YES |
| Image on Image |
Reduced-size image superimposed on the main image, zooming out the central view of the viewfinder |
| Battery type |
Internal battery and replaceable battery, 1x 18650 Li or 1x 18500 Li |
| Battery life |
Continuous operating time up to 16h |
| Connections |
USB Type C for connection to PC for downloading photos and videos |
| Communication |
Hotspot connection with app |
| Operating temperature |
-20℃～+50℃ |
| Protection index |
IP67, drop resistance from 1 metre |
| Weight |
1.117g |
| Dimensions |
438mm × 104mm × 93mm |
